~ New Short Form Available now ~
Distributor Wanted!
  Global Partners Are Welcomed.
      If you are interested in it, please contact us via sales@motien.com.tw

We provide optional heat sinker for standard series!
To extend the temperature range of providing higher output ratings, we provide 4 kinds of heat sinkers for 4 different package sizes as option:

Package Size Series  Extended full rating
 output temperature
1"X1"  VN30VNW30  Approx. 5°C
2"X1"  V7WV7E15V8V9
 VT30VT40VT50
 VTW30VTW60
 Approx. 6°C~7°C
2"X1.6"  VM  Approx. 10°C
2"X2"  M40AM60  Approx. 15°C
For more detailed, please check the individual data sheets of each series or write us with: sales@motien.com.tw

              New Update
Product highlight - UL Approval Series MOTIEN NEWS
Product highlight - Non-isolated Series (0.5A & 1.0A) MOTIEN NEWS
Product highlight - Fixed Input + RV1 Series MOTIEN NEWS
Product highlight - 2”x1”&1.6”x1” Package (7.5~60W) MOTIEN NEWS
Product highlight - 1”x1” Package (15~30W) MOTIEN NEWS
Product highlight - VB/VBW Series (1~9W) MOTIEN NEWS
Product highlight - DIP24 Package (1.5~15W) MOTIEN NEWS

              New Products
RV1  MOTIEN NEWS M7W  MOTIEN NEWS
‧Wide 2:1 Input Range ‧Wide 4:1 Input Range
‧1500Vdc~3000Vdc Isolation Voltage ‧1.6"x1" package
‧Fully regulated output ‧Extended operating Temperature Range:
‧No minimum load required     -40°C ~ +100°C Max.
‧Continuous Short Circuit Protection ‧Efficiency up to 90%
‧Efficiency up to 80% ‧Remote ON/OFF control
‧-40°C ~ +90°C Operating Temperature ‧Over Load / Over Voltage Protection
    Range

M9  MOTIEN NEWS VN 30W  MOTIEN NEWS
‧Wide 4:1 Input Range ‧Wide 2:1 Input Range
‧1.6"x1" package ‧High Power Density : 30W in 0.4 cubit inch
‧Extended operating Temperature Range: ‧Extended operating Temperature Range:
    -40°C ~ +100°C Max.     -40°C ~ +100°C Max.
‧Efficiency up to 91% ‧High Efficiency up to 92%
‧Remote ON/OFF control ‧Remote ON/OFF control
‧Over Load / Over Voltage Protection ‧Output Voltage Adjustable

VTW 60W  MOTIEN NEWS VNW 30W  MOTIEN NEWS
‧Ultra Wide 4:1 Input Range ‧Ultra Wide 4:1 Input Range
‧High Power Density : 60W in 0.8 cubit inch ‧High Power Density : 30W in 0.4 cubit inch
‧Extended operating Temperature Range: ‧Extended operating Temperature Range:
    -40°C ~ +100°C Max.     -40°C ~ +100°C Max.
‧High Efficiency up to 93% ‧High Efficiency up to 92%
‧Remote ON/OFF control ‧Remote ON/OFF control
‧Output Voltage Adjustable ‧Output Voltage Adjustable
