M60-60W Series
60W 2:1 Regulated Single output
The M60 series is a family of high performance 60W single output DC-DC converters. These converters combine nickle-coated copper package in a 2"×2" case with high performance features such as Active Clamp Technology, continuous short circuit protection with automatic restart and tight line / load regulation. Devices are encapsulated using flame retardant resin. Input voltages of 24 and 48 VDC with output voltage of 3.3, 5, 12, 15 VDC. High performance features include high efficiency operation up to 91% and output voltage accuracy of ±1% maximum.
● Wide 2:1 Input Range
● 1600 VDC Isolation
● No Minimum Load Required
● Efficiency up to 91%
● Operating Temperature Range -40 ~98°C max.
● Adjustable Output Voltage
● Remote ON/OFF Control ( CTRL )
● Continuous Short Circuit Protection
● Over Current Protection
● Over Voltage Protection
● Over Temperature Protection
● Soft Start
● Built-in EMC filter meets EN55032 ClassA without external components
● Optional Heat-sink
Download
No. | Title | Download |
---|---|---|
1 | M60-60W DATASHEET | |
2 | M60-60W CE_EN55032 55024 55035 | |
3 | M60 SERIES ROHS | |
4 | M60-60W EU DoC | |
5 | M60-60W UK DoC |
Model No. | Output Power | Input Voltage | Output Voltage | Output Current(mA) | Package |
---|---|---|---|---|---|
M60-243R3S60 | 46W | 18-36 | 3.3 | 14000 | 2×2 |
M60-2405S60 | 60W | 18-36 | 5 | 12000 | 2×2 |
M60-2412S60 | 60W | 18-36 | 12 | 5000 | 2×2 |
M60-2415S60 | 60W | 18-36 | 15 | 4000 | 2×2 |
M60-483R3S60 | 46W | 36-75 | 3.3 | 14000 | 2×2 |
M60-4805S60 | 60W | 36-75 | 5 | 12000 | 2×2 |
M60-4812S60 | 60W | 36-75 | 12 | 5000 | 2×2 |
M60-4815S60 | 60W | 36-75 | 15 | 4000 | 2×2 |
