PRODUCT
VV-10W Series
10W 4:1 Regulated Single & Dual output
The VV-10W series are high performance 10W single & dual output DC-DC converters. These converters are consisted with aluminum 24-pin DlL package with high performance features such as synchronous rectification, high efficiency and tight line / load regulation. Devices are encapsulated using flame retardant resin. Input voltages of 24 and 48 with output voltage of 3.3, 5, 12, 15, ±5, ±12, ±15 VDC. Features include high efficiency operation up to 91%.
● Wide 4:1 Input Range
● 1600 VDC Isolation
● Efficiency up to 91%
● Operating Temperature Range -40 ~ 100°C max.
● Continuous Short Circuit Protection
● Over Voltage Protection
● Over Load Protection
● DIP24 Package
● Soft Start
● Remote ON/OFF Control ( CTRL )
Download
| No. | Title | Download |
|---|---|---|
| 1 | VV-10W DATASHEET | |
| 2 | VV-10W CE_EN55032 55024 55035 | |
| 3 | VV-10W CB_IEC 60950-1 | |
| 4 | VV-10W CB_IEC62368-1 | |
| 5 | VV-10W UL 60950-1 62368-1 | |
| 6 | VV SERIES ROHS | |
| 7 | VV-10W EU DoC | |
| 8 | VV-10W UK DoC |
| Model No. | Output Power | Input Voltage | Output Voltage | Output Current(mA) | Package |
|---|---|---|---|---|---|
| VV-243R3S10 | 8.91W | 9-36 | 3.3 | 2700 | DIP 24 |
| VV-2405S10 | 10W | 9-36 | 5 | 2000 | DIP 24 |
| VV-2412S10 | 10W | 9-36 | 12 | 833 | DIP 24 |
| VV-2415S10 | 10W | 9-36 | 15 | 667 | DIP 24 |
| VV-2405D10 | 10W | 9-36 | ±5 | ±1000 | DIP 24 |
| VV-2412D10 | 10W | 9-36 | ±12 | ±417 | DIP 24 |
| VV-2415D10 | 10W | 9-36 | ±15 | ±330 | DIP 24 |
| VV-483R3S10 | 8.91W | 18-75 | 3.3 | 2700 | DIP 24 |
| VV-4805S10 | 10W | 18-75 | 5 | 2000 | DIP 24 |
| VV-4812S10 | 10W | 18-75 | 12 | 833 | DIP 24 |
| VV-4815S10 | 10W | 18-75 | 15 | 667 | DIP 24 |
| VV-4805D10 | 10W | 18-75 | ±5 | ±1000 | DIP 24 |
| VV-4812D10 | 10W | 18-75 | ±12 | ±417 | DIP 24 |
| VV-4815D10 | 10W | 18-75 | ±15 | ±330 | DIP 24 |
