R6-6W 系列
6W 2:1 稳压单/双输出
R6系列是具成本效率的6W单/双输出直流对直流电源转换器。R6-6W 系列为DIP24塑料外壳包装，具备1500 Vdc. ~ 3500 Vdc. 输入/输出隔离电压,连续短路保护,自动重启与高线变动率/负载变动率。使用不易燃树脂，输入电压12,24, 48 Vdc.，输出电压5, 9, 12, 15, 24, ±5, ±9, ±12, ±15, ±24 Vdc.，效率高达81%，输出电压准确度最高可达±1%。
● 宽范围2:1输入
● 内部 SMD 构造
● 1500 VDC 至3500 VDC 之隔离电压
● 连续短路保护
● 效率高达 81%
● 操作温度范围 -40°C ~+85°C
● 标准塑料外壳
Download
| No. | Title | Download |
|---|---|---|
| 1 | R6-6W DATASHEET | |
| 2 | R6-6W CE_EN55032 55024 55035 | |
| 3 | R6 SERIES ROHS | |
| 4 | R6-6W EU Doc | |
| 5 | R6-6W UK Doc |
H字尾为 3.5KVdc 隔离
| 型号 | 输出功率 | 输入电压范围(VDC) | 输出电压(VDC) | 输出电流 | 包装 |
|---|---|---|---|---|---|
| R6-1205S6 | 6W | 9-18 | 5 | 1200 | DIP 24 |
| R6-1209S6 | 6W | 9-18 | 9 | 666 | DIP 24 |
| R6-1212S6 | 6W | 9-18 | 12 | 500 | DIP 24 |
| R6-1215S6 | 6W | 9-18 | 15 | 400 | DIP 24 |
| R6-1224S6 | 6W | 9-18 | 24 | 250 | DIP 24 |
| R6-1205D6 | 6W | 9-18 | ±5 | ±600 | DIP 24 |
| R6-1209D6 | 6W | 9-18 | ±9 | ±333 | DIP 24 |
| R6-1212D6 | 6W | 9-18 | ±12 | ±250 | DIP 24 |
| R6-1215D6 | 6W | 9-18 | ±15 | ±200 | DIP 24 |
| R6-1224D6 | 6W | 9-18 | ±24 | ±125 | DIP 24 |
| R6-2405S6 | 6W | 18-36 | 5 | 1200 | DIP 24 |
| R6-2409S6 | 6W | 18-36 | 9 | 666 | DIP 24 |
| R6-2412S6 | 6W | 18-36 | 12 | 500 | DIP 24 |
| R6-2415S6 | 6W | 18-36 | 15 | 400 | DIP 24 |
| R6-2424S6 | 6W | 18-36 | 24 | 250 | DIP 24 |
| R6-2405D6 | 6W | 18-36 | ±5 | ±600 | DIP 24 |
| R6-2409D6 | 6W | 18-36 | ±9 | ±333 | DIP 24 |
| R6-2412D6 | 6W | 18-36 | ±12 | ±250 | DIP 24 |
| R6-2415D6 | 6W | 18-36 | ±15 | ±200 | DIP 24 |
| R6-2424D6 | 6W | 18-36 | ±24 | ±125 | DIP 24 |
| R6-4805S6 | 6W | 36-72 | 5 | 1200 | DIP 24 |
| R6-4809S6 | 6W | 36-72 | 9 | 666 | DIP 24 |
| R6-4812S6 | 6W | 36-72 | 12 | 500 | DIP 24 |
| R6-4815S6 | 6W | 36-72 | 15 | 400 | DIP 24 |
| R6-4824S6 | 6W | 36-72 | 24 | 250 | DIP 24 |
| R6-4805D6 | 6W | 36-72 | ±5 | ±600 | DIP 24 |
| R6-4809D6 | 6W | 36-72 | ±9 | ±333 | DIP 24 |
| R6-4812D6 | 6W | 36-72 | ±12 | ±250 | DIP 24 |
| R6-4815D6 | 6W | 36-72 | ±15 | ±200 | DIP 24 |
| R6-4824D6 | 6W | 36-72 | ±24 | ±125 | DIP 24 |
