M1-2W 系列
2W 半稳压单/双输出
M1系列是具有成本效率的2W单/双输出直流对直流电源转换器。M1-2W 系列为低成本,高效率,半稳压产品，包装为SIP7，使用不易燃树脂。输入电压为5, 12,15, 24, 48 Vdc.，输出电压为5,9,12,15,±5,±9,±12,±15 Vdc.， 输出电压准确度最高+2%~-4%，产品皆具备输入范围±10%公差与低连波噪声。
● 单排七脚包装
● 半稳压输出
● 1000 VDC 至3000 VDC 之隔离电压
● 低连波噪声
● 效率高达 89%
● 操作温度范围 -40°C ~+85°C
● 绝缘黑色塑料外壳
Download
| No. | Title | Download |
|---|---|---|
| 1 | M1-2W DATASHEET | |
| 2 | M1-2W CE_EN55032 55024 55035 | |
| 3 | M1 SERIES ROHS | |
| 4 | M1-2W EU Doc | |
| 5 | M1-2W UK Doc |
H字尾为 3 K Vdc 隔离
| 型号 | 输出功率 | 输入电压范围(VDC) | 输出电压(VDC) | 输出电流 | 包装 |
|---|---|---|---|---|---|
| M1-0505S2 | 2W | 5 | ±5 | ±200 | SIP 7 |
| M1-0509S2 | 2W | 5 | ±9 | ±111.1 | SIP 7 |
| M1-0512S2 | 2W | 5 | ±12 | ±83.3 | SIP 7 |
| M1-0515S2 | 2W | 5 | ±15 | ±66.6 | SIP 7 |
| M1-1205S2 | 2W | 12 | ±5 | ±200 | SIP 7 |
| M1-1209S2 | 2W | 12 | ±9 | ±111.1 | SIP 7 |
| M1-1212S2 | 2W | 12 | ±12 | ±83.3 | SIP 7 |
| M1-1215S2 | 2W | 12 | ±15 | ±66.6 | SIP 7 |
| M1-1505S2 | 2W | 15 | ±5 | ±200 | SIP 7 |
| M1-1509S2 | 2W | 15 | ±9 | ±111.1 | SIP 7 |
| M1-1512S2 | 2W | 15 | ±12 | ±83.3 | SIP 7 |
| M1-1515S2 | 2W | 15 | ±15 | ±66.6 | SIP 7 |
| M1-2405S2 | 2W | 24 | ±5 | ±200 | SIP 7 |
| M1-2409S2 | 2W | 24 | ±9 | ±111.1 | SIP 7 |
| M1-2412S2 | 2W | 24 | ±12 | ±83.3 | SIP 7 |
| M1-2415S2 | 2W | 24 | ±15 | ±66.6 | SIP 7 |
| M1-0505SS2 | 2W | 5 | 5 | 400 | SIP 7 |
| M1-0509SS2 | 2W | 5 | 9 | 222.2 | SIP 7 |
| M1-0512SS2 | 2W | 5 | 12 | 166.6 | SIP 7 |
| M1-0515SS2 | 2W | 5 | 15 | 133.3 | SIP 7 |
| M1-1205SS2 | 2W | 12 | 5 | 400 | SIP 7 |
| M1-1209SS2 | 2W | 12 | 9 | 222.2 | SIP 7 |
| M1-1212SS2 | 2W | 12 | 12 | 166.6 | SIP 7 |
| M1-1215SS2 | 2W | 12 | 15 | 133.3 | SIP 7 |
| M1-1505SS2 | 2W | 15 | 5 | 400 | SIP 7 |
| M1-1509SS2 | 2W | 15 | 9 | 222.2 | SIP 7 |
| M1-1512SS2 | 2W | 15 | 12 | 166.6 | SIP 7 |
| M1-1515SS2 | 2W | 15 | 15 | 133.3 | SIP 7 |
| M1-2405SS2 | 2W | 24 | 5 | 400 | SIP 7 |
| M1-2409SS2 | 2W | 24 | 9 | 222.2 | SIP 7 |
| M1-2412SS2 | 2W | 24 | 12 | 166.6 | SIP 7 |
| M1-2415SS2 | 2W | 24 | 15 | 133.3 | SIP 7 |
