VL2-2W Series
2W Unregulated Single & Dual output
The VL2 series is a family of cost effective 2W single & dual output DC-DC converters. These converters achieve low cost and miniature SIP size without compromising performance. Devices are encapsulated with flame retardant resin. Input voltages are 5, 12, 15, 24 VDC. with output voltage of 3.3, 5, 9, 12, 15, ±5, ±9, ±12, ±15, +15V / -9 VDC. Special featuring long term output short circuit protection . Standard features include an input range of ±10% tolerance and low output noise and ripple.
● SIP7 Package
● 5200 VDC High Isolation
● Efficiency up to 88%
● Long Term Short Circuit Protection
● Operation Temperature Range -40 ~ 80°C max.
● Low coupling capacitance
● Dedicated for IGBT applications
Download
| No. | Title | Download |
|---|---|---|
| 1 | VL2-2W DATASHEET | |
| 2 | VL2-2W CE_EN55032 55024 55035 | |
| 3 | VL2 SERIES ROHS | |
| 4 | VL2-2W EU DoC | |
| 5 | VL2-2W UK DoC |
| Model No. | Output Power | Input Voltage | Output Voltage | Output Current(mA) | Package |
|---|---|---|---|---|---|
| VL2-053R3SS | 1.65W | 5 ( 4.5 ~ 5.5 ) | 3.3 | 500 | SIP 7 |
| VL2-0505SS | 2W | 5 ( 4.5 ~ 5.5 ) | 5 | 400 | SIP 7 |
| VL2-0509SS | 2W | 5 ( 4.5 ~ 5.5 ) | 9 | 222 | SIP 7 |
| VL2-0512SS | 2W | 5 ( 4.5 ~ 5.5 ) | 12 | 167 | SIP 7 |
| VL2-0515SS | 2W | 5 ( 4.5 ~ 5.5 ) | 15 | 133 | SIP 7 |
| VL2-123R3SS | 1.65W | 12 ( 10.8 ~ 13.2 ) | 3.3 | 500 | SIP 7 |
| VL2-1205SS | 2W | 12 ( 10.8 ~ 13.2 ) | 5 | 400 | SIP 7 |
| VL2-1209SS | 2W | 12 ( 10.8 ~ 13.2 ) | 9 | 222 | SIP 7 |
| VL2-1212SS | 2W | 12 ( 10.8 ~ 13.2 ) | 12 | 167 | SIP 7 |
| VL2-1215SS | 2W | 12 ( 10.8 ~ 13.2 ) | 15 | 133 | SIP 7 |
| VL2-153R3SS | 1.65W | 15 ( 13.5 ~ 16.5 ) | 3.3 | 500 | SIP 7 |
| VL2-1505SS | 2W | 15 ( 13.5 ~ 16.5 ) | 5 | 400 | SIP 7 |
| VL2-1509SS | 2W | 15 ( 13.5 ~ 16.5 ) | 9 | 222 | SIP 7 |
| VL2-1512SS | 2W | 15 ( 13.5 ~ 16.5 ) | 12 | 167 | SIP 7 |
| VL2-1515SS | 2W | 15 ( 13.5 ~ 16.5 ) | 15 | 133 | SIP 7 |
| VL2-243R3SS | 1.65W | 24 ( 21.6 ~ 26.4 ) | 3.3 | 500 | SIP 7 |
| VL2-2405SS | 2W | 24 ( 21.6 ~ 26.4 ) | 5 | 400 | SIP 7 |
| VL2-2409SS | 2W | 24 ( 21.6 ~ 26.4 ) | 9 | 222 | SIP 7 |
| VL2-2412SS | 2W | 24 ( 21.6 ~ 26.4 ) | 12 | 167 | SIP 7 |
| VL2-2415SS | 2W | 24 ( 21.6 ~ 26.4 ) | 15 | 133 | SIP 7 |
| VL2-0505S | 2W | 5 ( 4.5 ~ 5.5 ) | ±5 | ±200 | SIP 7 |
| VL2-0509S | 2W | 5 ( 4.5 ~ 5.5 ) | ±9 | ±111 | SIP 7 |
| VL2-0512S | 2W | 5 ( 4.5 ~ 5.5 ) | ±12 | ±83.3 | SIP 7 |
| VL2-0515S | 2W | 5 ( 4.5 ~ 5.5 ) | ±15 | ±66.7 | SIP 7 |
| VL2-051509S | 2W | 5 ( 4.5 ~ 5.5 ) | +15/-9 | +66.7/-111 | SIP 7 |
| VL2-1205S | 2W | 12 ( 10.8 ~ 13.2 ) | ±5 | ±200 | SIP 7 |
| VL2-1209S | 2W | 12 ( 10.8 ~ 13.2 ) | ±9 | ±111 | SIP 7 |
| VL2-1212S | 2W | 12 ( 10.8 ~ 13.2 ) | ±12 | ±83.3 | SIP 7 |
| VL2-1215S | 2W | 12 ( 10.8 ~ 13.2 ) | ±15 | ±66.7 | SIP 7 |
| VL2-121509S | 2W | 12 ( 10.8 ~ 13.2 ) | +15/-9 | +66.7/-111 | SIP 7 |
| VL2-1505S | 2W | 15 ( 13.5 ~ 16.5 ) | ±5 | ±200 | SIP 7 |
| VL2-1509S | 2W | 15 ( 13.5 ~ 16.5 ) | ±9 | ±111 | SIP 7 |
| VL2-1512S | 2W | 15 ( 13.5 ~ 16.5 ) | ±12 | ±83.3 | SIP 7 |
| VL2-1515S | 2W | 15 ( 13.5 ~ 16.5 ) | ±15 | ±66.7 | SIP 7 |
| VL2-151509S | 2W | 15 ( 13.5 ~ 16.5 ) | +15/-9 | +66.7/-111 | SIP 7 |
| VL2-2405S | 2W | 24 ( 21.6 ~ 26.4 ) | ±5 | ±200 | SIP 7 |
| VL2-2409S | 2W | 24 ( 21.6 ~ 26.4 ) | ±9 | ±111 | SIP 7 |
| VL2-2412S | 2W | 24 ( 21.6 ~ 26.4 ) | ±12 | ±83.3 | SIP 7 |
| VL2-2415S | 2W | 24 ( 21.6 ~ 26.4 ) | ±15 | ±66.7 | SIP 7 |
| VL2-241509S | 2W | 24 ( 21.6 ~ 26.4 ) | +15/-9 | +66.7/-111 | SIP 7 |
